Assembly
13.00 | MPG-plus | Assembly and operating manual | en | 389216
21
Assembly options
Item Mounting
MPG-plus
10 12 16 20 25 32 40 50 64
Side A
1 Mounting screw M
1.2
M
1.6
M2 M
2.5
M3 M4 M4 M5 M5
Max. depth of
engagement
from locating
surface [mm]
2.2 2.3 4 5.5 7.4 8.9 8.9 10.9 10.9
2 Centering sleeve Ø2 Ø2.5 Ø3 Ø4 Ø5 Ø6 Ø6 Ø8 Ø8
Side B
4 Mounting screw M
1.2
M
1.6
M2 M
2.5
M3 M4 M4 M5 M5
Max. depth of
engagement
from locating
surface [mm]
2.2 3.1 4 6 6.9 8.9 8.9 10.4 10.4
3 Centering sleeve Ø2 Ø2.5 Ø3 Ø4 Ø5 Ø6 Ø6 Ø8 Ø8
Side C
5 Mounting screw - - M
1.6
M2 M
2.5
M3 M3 M4 M4
Mounting screw
according to
standard
DIN EN ISO 4762
Max. strength class 8.8
3 Centering sleeve Ø2 Ø2.5 Ø3 Ø4 Ø5 Ø6 Ø6 Ø8 Ø8
Connections at the
base jaws
Designation
MPG-plus
10 12 16 20 25 32 40 50 64
Thread in base jaws - - M3 M4 M4 M5 M5 M6 M8
Bore hole for
fastening screws
Ø1.6 Ø2 - - - - - - -
Max. depth of
engagement from
locating surface [mm]
- - 3 3.5 4 5 6 8 10
Max. tightening
torque of the
fastening screws [Nm]
- - 1.2 3.1 3.1 6.1 6.1 10 25
Fitting bore for
centering pins [mm]
- - 1.5 1.5 1.5 2 2.5 3 4
