Assembly
13.00 | MPG-plus | Assembly and operating manual | en | 389216
23
5.3 Mounting the sensor
NOTE
Observe the assembly and operating manual of the sensor for
mounting and connecting.
The product is prepared for the use of sensors.
• For the exact type designations of suitable sensors, please see
catalog datasheet and Overview of sensors [
}
23].
• For technical data for the suitable sensors, see assembly and
operating manual and catalog datasheet.
– The assembly and operating manual and catalog datasheet
are included in the scope of delivery for the sensors and are
available at schunk.com.
• Information on handling sensors is available at schunk.com or
from SCHUNK contact persons.
5.3.1 Overview of sensors
Designation
MPG-plus
10 12 16 20 25 32 40 50 64
Programmable magnetic
switch MMS 22-PI2
– – – – X X X X X
Inductive proximity switch IN 30 X X X – – – – – –
Inductive proximity switch IN 40 – – – X X X X X X
Magnetic switch MMS 22-IOL – – – – X X X X X
Analog magnetic switch MMS
22-A-10V
– – – – X X X X X
Programmable magnetic
switch MMS-P 22
– – – – X X X X X
Flexible position sensor FPS
on FPS-S 13
– – – Special
housing
version
X X X
Flexible position sensor FPS
on MMS 22-A-5V
– – – – X X X X X
Optical distance sensor OAS – – – – X X X X X
Inductive proximity switch IN 5 – – – – X X X X X
