Maintenance
44
13.00 | MPG-plus | Assembly and operating manual | en | 389216
7.3 Lubricants/Lubrication points (basic lubrication)
SCHUNK recommends the lubricants listed.
During maintenance, treat all greased areas with lubricant. Thinly
apply lubricant with a lint-free cloth.
Lubricant point Lubricant
Cross roller guide microGLEIT GP 360
All seals Renolit HLT 2
7.4 Servicing the product
WARNING
Risk of injury due to spring forces!
The cover is under spring tension.
• Carefully disassemble the product.
Ø Clean all parts thoroughly, check for damage and wear
Ø Oil or grease external steel parts
Ø Disassemble the product.
Ø Treat all grease areas with lubricant,
Lubricants/Lubrication points (basic lubrication) [
}
44]
Ø Replace all wear parts / seals.
–Position of the wearing parts, Drawings [
}
44].
–Seal kit, Sealing kit [
}
7].
Ø Assemble product in the reverse order. In doing so, observe the
following:
Unless otherwise specified, secure all screws and nuts with
Loctite no. 243 and tighten with the appropriate tightening
torque.
7.5 Drawings
The following figures are example images.
They serve for illustration and assignment of the spare parts.
Variations are possible depending on size and variant.
