7 Maintenance
7.1 Notes
Original spare parts
Use only original spare parts of SCHUNK when replacing spare and
wear parts.
Exchange of housing and base jaws
The base jaws and the guidance in the housing are matched. To
exchange these parts, send the product with a repair order to
SCHUNK.
Maintenance of version with gripping force maintenance I.D.
gripping and O.D. gripping
The pistons have to be aligned using an assembly device.
Therefore we recommend to have the module serviced and the
seals replaced by SCHUNK.
7.2 Maintenance and lubrication intervals
CAUTION
Material damage due to hardening lubricants!
Lubricants harden more quickly at temperatures above 60°C,
leading to possible product damage.
• Reduce the lubricant intervals accordingly.
Interval (million cycles)
MPG-plus
Maintenance work
10 -
12
16 -
20
25 -
32
40 -
50
64
10 15 5 4 3 Clean all parts thoroughly, check
for damage and wear, if
necessary replace seals and
wearing parts.
• Position of the wearing parts,
Drawings [
}
44]
• Seal kit, Sealing kit [
}
7]
10 15 5 4 3 Treat all grease areas with
lubricant, Lubricants/Lubrication
points (basic lubrication) [
}
44]
10 15 5 4 3 Oil or grease external steel
parts.
