Assembly
09.00 | MPG | Assembly and Operating Manual | en | 389213
23
Item Mounting
MPG
16 20 25 32 40 50 64 80
Side A
1 Screw M2 M2.5 M3 M4 M4 M5 M5 M6
Max. depth of
engagement [mm]
4 6 7.4 8 9 11 11 12.9
2 Centering sleeve [mm] Ø3 Ø4 Ø5 Ø6 Ø6 Ø8 Ø8 Ø10
Side B
3 Screw M2 M2.5 M3 M4 M4 M5 M5 M6
Max. depth of
engagement [mm]
4 3.5 6 6 8 10 10 13.9
2 Centering sleeve [mm] Ø3 - - - - - - -
Side C
4 Screw - M2x20 M2.5x
25
M3x25 M3x30 M4x35 M4x40 M5x55
Screw according to
standard
DIN EN ISO 4762 Max. strength class 8.8
2 Centering sleeve [mm] Ø3 - - - - - - -
Connections at the base jaws
5 Bore for mounting
screws [mm]
Ø2.5 Ø3 Ø3 Ø4 Ø4 Ø5 Ø6 Ø8
