SCHUNK PZN-plus 40 User Manual

Technical data
18 210.00 | PZN-plus | Assembly and Operating Manual | en | 389374
3 Technical data
Designation Value
Pressure medium Compressed air, compressed air
quality according to ISO 8573‐
1:2010 [7:4:4]
Nominal operating pressure [bar] 6
Minimum pressure [bar]
without maintenance of gripping
force
2.5
Minimum pressure [bar]
with maintenance of gripping
force
4
Maximum pressure [bar]
without maintenance of gripping
force
8
Maximum pressure [bar]
with maintenance of gripping
force
6.5
Maximum pressure [bar]
with force intensified cylinder
6
Pressure range for air purge [bar] 0.5 – 1
Ambient conditions and operating conditions
Ambient temperature [°C]
min. +5
Ambient temperature [°C]
max. +90
Ambient temperature [°C]
max. (variant V/HT) +130
IP rating* 40
IP rating (variant SD) 64
Noise emission [dB(A)] ≤70
* For use in dirty ambient conditions (e.g. sprayed water, vapors,
abrasion or processing dust) SCHUNK offers corresponding
product options as standard. SCHUNK also offers customized
solutions for special applications in dirty ambient conditions.
More technical data is included in the catalog data sheet.
Whichever is the latest version.
