Assembly
210.00 | PZN-plus | Assembly and Operating Manual | en | 389374 25
1 Main connections (Hose connection)
(A = open, B = close)
2 Hose-free direct connection
(a = open, b = close)
3 Air purge connection
Hose-free direct connection
4 Product
5 O-ring
6 Attachment
Size Main air
connections
Hose-free direct
connection
Air purge
connection
40 M3 M3 M3
50 M5 M3 M5
64 M5 M4 M5
80 M5 M4 M5
100 G1/8" M5 M5
125 G1/8" M5 M5
160 G1/8" M4 M5
200 G1/8" M5 M5
240 G1/4" M5 M5
300 G1/4" M8 M5
380 G1/4" M8 M5
Tab.: Thread diameter of the air connections
