SCHUNK PZN-plus 40 User Manual

Assembly
210.00 | PZN-plus | Assembly and Operating Manual | en | 389374 39
Analog signal [V]
Stroke [mm]
Signal Real
Signal Optimal
1. Turn the sensor (1) into the groove (2).
OR: Slide the sensor (1) into the groove (2) until the sensor (1)
stops at the T-nut (3).
2. Secure the sensor (1) using the set-screw (4).
Tightening torque: 10 Ncm
