Commissioning and maintenance
50 02.00|ROTA TP |en
4 Insert the piston cover with the O-ring (item 6, 53) and ensure
that the spring ring / securing nut (item 40) can spring easily in
the groove. Use the supplied assembly tool (item 80) to mount
the lock nut.
ROTA TP 315-105, ROTA TP 350-115, ROTA TP-LH 315-105,
ROTA TP-LH 350-115:
Mount the screws (item 40) and tighten them alternately.
5 Place down the chuck holder with the O-rings (item 7, 52) and
screw it with the hexagon socket head screws (item 39).
6 Lubricate valve system (item 18) and valve bore hole with oil,
install and close with plug-in screw and O-ring (item 3).
NOTE
All parts of the ROTA TP-type front-end power chuck are
lightweight. As such, hard hammer blows should never be
used during assembly.
7 Assembly of the distributor ring (see "Function" chapter (ļ 4
,
Page 27).
8 Screw the distributor ring cover (item 15) on the chuck body
with screws (item 35).
