Spare parts
02.00|ROTA TP |en
51
Spare parts
When ordering spare parts, it is imperative to specify the type,
size and above all the manufacturing no of the chuck.
Seals, sealing elements, screw connections, springs, bearings,
screws and wiper bars plus parts coming into contact with the
workpiece are not covered by the warranty.
Item
Designation
1
Chuck body
2
Base jaw
3
Piston with thread
4
Bushing
5
Sealing disk
6
Piston cover
7
Mount
8
T-nut
9
Distributor ring
11
Centering ring
12
Spacer ring
13
Locking screw
15
Distributor ring cover
18
Double check valve
34
Set-screw DIN 914
35
Screws (DIN EN ISO 4762/7984)
36
Screws
37
Screws ISO 4762
38
Screws – 10.9 (DIN EN ISO 4762/109)
39
Screws
40
Safety ring
Locking nut
Screws (ROTA TP 315-105)
47
O-ring
48
O-ring
49
O-ring
50
O-ring
51
O-ring
52
O-ring
53
O-ring
65
Copper seal
66
Profile seal
67
Angle
68
Eye bolt
