SCHUNK ROTA TP User Manual

Appendix on Declaration of Incorporation, as per 2006/42/EC, Annex II, No. 1 B
02.00|ROTA TP |en
55
Appendix on Declaration of Incorporation, as per 2006/42/EC, Annex II, No. 1 B
1. Description of the basic safety and health protection requirements, as per 2006/42/EC, Annex I, that
apply to and are fulfilled for the scope of the partly completed machinery:
Product designation
Pneumatic Chuck
Type designation
ROTA TP: 125-26; 160-38; 200-52; 250-68; 315-90; 315-105; 350-115
ROTA TP-LH: 350-115
ID number
0816101; 0816102; 0816103; 0816111; 0816112; 0816113; 0816121; 0816122; 0816123;
0816125; 0816128; 0816131; 0816132; 0816133; 0816135; 0816138; 0816141; 0816142;
0816143; 0816145; 0816148; 0816151; 0816152; 0816155; 0816158; 0816161; 0816162;
0816165; 0816168; 0816150; 0816160; 0816170
To be provided by the System Integrator for the overall machine
⇓
Fulfilled for the scope of the partly completed machine
⇓
Not relevant
⇓
1.1
Essential Requirements
1.1.1
Definitions
X
1.1.2
Principles of safety integration
X
1.1.3
Materials and products
X
1.1.4
Lighting
X
1.1.5
Design of machinery to facilitate its handling
X
1.1.6
Ergonomics
X
1.1.7
Operating positions
X
1.1.8
Seating
X
1.2
Control Systems
1.2.1
Safety and reliability of control systems
X
1.2.2
Control devices
X
1.2.3
Starting
X
1.2.4
Stopping
X
1.2.4.1
Normal stop
X
1.2.4.2
Operational stop
X
1.2.4.3
Emergency stop
X
1.2.4.4
Assembly of machinery
X
1.2.5
Selection of control or operating modes
X
1.2.6
Failure of the power supply
X
1.3
Protection against mechanical hazards
1.3.1
Risk of loss of stability
X
1.3.2
Risk of break-up during operation
X
1.3.3
Risks due to falling or ejected objects
X
1.3.4
Risks due to surfaces, edges or angles
X
1.3.5
Risks related to combined machinery
X
1.3.6
Risks related to variations in operating conditions
X
1.3.7
Risks related to moving parts
X
1.3.8
Choice of protection against risks arising from moving parts
X
1.3.8.1
Moving transmission parts
X
1.3.8.2
Moving parts involved in the process
X
1.3.9
Risks of uncontrolled movements
X
1.4
Required characteristics of guards and protective devices
1.4.1
General requirements
X
1.4.2
Special requirements for guards
X
1.4.2.1
Fixed guards
X
