General
6 02.00|ROTA TP |en
Applicable documents
• General terms of business*
• Catalog data sheet of the purchased product *
• Calculation of the jaw centrifugal forces, "Technology" chapter
in the lathe chuck catalog *
The documents marked with an asterisk (*) can be downloaded on
our homepage schunk.com
Sizes
This operating manual applies to the following sizes:
• ROTA TP
125-26; 160-38; 200-52; 250-68; 315-90; 315-105; 315-115
• ROTA TP LH
350-115
Warranty
The warranty period is 24 months after delivery date from factory or
500 000 cycles*, if it is used as intended, under the following conditions:
• Observe the applicable documents ( 1.1.2, Page 6)
• Observe the ambient conditions and operating conditions,
( 2.6, Page 9)
• Observe the specified maintenance and lubrication intervals,
( 7, Page 43)
Parts touching the workpiece and wear parts are not included in
the warranty.
* A cycle consists of a complete clamping process ("Open" and "Close").
Scope of delivery
1
Power lathe chucks
6
T-nuts
2
Elbow connectors
2
Straight connectors
1
Spacer ring
1
Headless screw for fastening the distributor ring
1
Angle for eye bolt
1
Eye bolt
Studs for assembling the chuck
1
Operating manual
1.1.2
1.1.3
1.2
1.3
