Translation of the original declaration of incorporation
54 02.00|ROTA TP |en
Translation of the original declaration of incorporation
in terms of the Directive 2006/42/EG, Annex II, Part 1.B of the European Parliament and of
the Council on machinery.
Manufacturer/
Distributor
H.-D. SCHUNK GmbH & Co. Spanntechnik KG
Lothringer Str. 23
D-88512 Mengen
We hereby declare that on the date of the declaration the following partly completed ma-
chine complied with all basic safety and health regulations found in the directive
2006/42/EC of the European Parliament and of the Council on machinery. The declaration
is rendered invalid if modifications are made to the product.
Product designation:
Pneumatic Chuck ROTA TP / ROTA TP-LH
TP: 125-26; 160-38; 200-52; 250-68; 315-90; 315-105; 350-115
TP-LH: 350-115
ID number
0816101; 0816102; 0816103; 0816111; 0816112; 0816113; 0816121; 0816122;
0816123; 0816125; 0816128; 0816131; 0816132; 0816133; 0816135; 0816138;
0816141; 0816142; 0816143; 0816145; 0816148; 0816151; 0816152; 0816155;
0816158; 0816161; 0816162; 0816165; 0816168; 0816150; 0816160; 0816170
The partly completed machine may not be put into operation until conformity of the ma-
chine into which the partly completed machine is to be installed with the provisions of the
Machinery Directive (2006/42/EC) is confirmed.
Applied harmonized standards, especially:
EN ISO 12100:2010
Safety of machinery - General principles for design -
Risk assessment and risk reduction
EN 1550:1997+A1:2008
Machine-tools safety - Safety requirements for the design and
construction of work holding chucks
Other related technical standards and specifications:
DIN ISO 702-1:2010-04
Machine tools - Connecting dimensions of spindle noses and work
holding chucks - Part 1: Conical connection
DIN ISO 702-4:2010-04
Machine tools - Connecting dimensions of spindle noses and work
holding chucks - Part 4: cylindrical assembly
VDI 3106:2004-04
Determination of permissible speed (rpm) of lathe chucks (jaw chucks)
The manufacturer agrees to forward on demand the relevant technical documentation for
the partly completed machinery in electronic form to national authorities.
The relevant technical documentation according to Annex VII, Part B, belonging to the
partly completed machinery, has been created.
Person authorized to compile the technical documentation:
Philipp Schräder, Address: see manufacturer's address
Mengen, September 2017
p.p. Philipp Schräder; Head of Engineering Design
10
