Troubleshooting
30 01.00|1372106_AFS3 138 PMI_AFS3 138 MMS |en
Troubleshooting
The AFS3 138 PMI is not working
No control of switching valves due to missing signal output
Possible cause
Remedial measures
Position measuring system for
monitoring the clamping slide
positions is not working
properly
Check all screw connections of
the sensor, as well as the target
mounting for correct seating.
Adjust gap distance of the
position measuring system for
adjustable target. Teach in
switching windows of the
electronic position measuring
system with teaching device
(accessory) and program in.
Position measuring system for
monitoring the clamping slide
positions is not reporting any
signal
Check sensor and feed cable of
the position measuring system
for damage (replace position
measuring system or connection
cable if required)
Proximity switch not switching
Readjust positions. Adjust and
tighten position and switching
distance.
Proximity switch not switching
Check the proximity switch on
the sensor head and on the
connection cable for damage
(replace proximity switch if
necessary).
