SCHUNK VERO-S - Assembly, Connection, Technical Data Proximity Switch IN60

Sensor for presence monitoring of the clamping pallet
01.00|1372106_AFS3 138 PMI_AFS3 138 MMS |en
37
Assembly, connection, technical data proximity switch IN60
Technical data
Sensor IN-60-M8 with circular plug M8: ID no.: 0301485
Optional accessories
• Angular plug with feeder cable WK 3-M8 plug connection 3
meter cable length (individual): ID no.: 0301594
• Angular plug with feeder cable WK 5-M8 plug connection 5
meter cable length (Individual): ID no.: 0301502
Characterization
Value / description
Switching function
Closer
Type of switching
PNP
Switching distance [mm]
1.5
Ambient temperature [°C]
-25 to +70
IP rating (sensor)
67
IP class (sensor connected)
67
LED display in sensor
no
Type of voltage
DC
Rated voltage [V]
24
min. voltage [V]
10
max. voltage [V]
30
max. current on contact [A]
0.2
Cable diameter [mm]
3.5
min. bending radius
(dynamically) [mm]
35
min. bending radius (statically)
[mm]
17.5
Number of cores
3
