Mounting / connection / programming of the AFS3 138 MMS
24 01.00|1372106_AFS3 138 PMI_AFS3 138 MMS |en
permanently in the magnetic switch and can be readjusted if
required. The programming tools are included in the scope of
delivery, consisting of plastic bracket with magnetic insert and
an Allen key to jam sensor in the housing of the AFS3 138 MMS.
15 Perform functional test of the electronic magnetic switch for
the clamping slide monitoring. Open clamping system → insert
clamping pallet → close clamping system.
16 Inspect signal output of the electronic magnetic switch for the
clamping slide request, signal output for clamped clamping
pallet and for opened clamping system required.
17 Insert seals in the housing and in the lid, screw on lid.
18 Monitoring system AFS3 138 MMS is operational
Connecting the AFS3 138 MMS
Sensor MMS 22-PI2-S-8-NPN:
The AFS3 138 MMS has an electronic sensor with two
programmable switching positions for monitoring the end
positions of the clamping slide positions.
When installing the monitoring system directly from the factory,
the system comes adjusted and operational.
When retrofitting, the sensor system must be taught-in to the
clamping slide-stroke position on that clamping module (see
manual "Programming the switching position" ( 7.3, Page 26)
).
Designation
Value / description
Switching function
Closer
Type of switching
NPN
Number of switching points
2
Ambient temperature [°C]
-10 to +70
IP rating (sensor)
67
IP class (sensor connected)
67
Type of voltage
DC
Rated voltage [V]
24
min. voltage [V]
10
max. voltage [V]
30
min. bending radius
(dynamically) [mm]
21
min. bending radius (statically)
[mm]
10.5
7.2
