Troubleshooting
32 01.00|1372106_AFS3 138 PMI_AFS3 138 MMS |en
socket screwdriver. Check target
for fixed jamming to the
clamping slide. Check sensor
head, attachment screw and
installation groove for damage.
Replace magnetic switch type
MMS PI2 if required.
Proximity switch not switching
Readjust position. Adjust and
tighten position and switching
distance.
Proximity switch not switching
Check the proximity switch on
the sensor head and on the
connection cable for damage
(replace proximity switch if
necessary)
Proximity switch moves
independently
Tighten bracket according to
tightening torque specification,
check installation housing for
damage and check collision
contact to the proximity switch.
Replace proximity switch type
IN if required.
Mechanical tensile force
influenced on connection cable
Check sensor cable for damage.
Readjust sensor position and
teach in switching window
again. Replace proximity switch
or magnetic switch if required.
Cable plug-in connection to the
supply cable
Check plug connections, if
necessary tighten. Proximity
switch type IN or replace
specially available feed cable if
required.
