SCIFIT Scientic Solutions For Fitness SCIFIT Scientic Solutions For Fitness SCIFIT
SPECIFICATIONS
MECHANICAL REMOVAL/REPLACEMENT
LIPPED EDGE
FACING HANDLE
ALIGN TABS WITH
HOLES ON THE TUBE
Position the clamp sleeve with the lipped
edge facing the molded handle, then slide
it onto the handlebar tube.
Step 1:
Align the tabs of the inner tube end plug
and insert it into the end of the tube,
making sure the tabs pop up through the
open holes.
Step 2:
* 3/16 T-Handle Allen Hex * Silicon Spray *Small dead blow hammer * Loctite 271 Tools Required:
SPECIFICATIONS
LEFT hAnDLEBAr rEpLAcEmEnT
