SCIFIT STEP ONE - Poly-V Pulley

SPECIFICATIONS
MECHANICAL PARTS REMOVAL/REPLACEMENT
51
SCIFIT Scientic Solutions For Fitness SCIFIT Scientic Solutions For Fitness SCIFIT
Step 5:
SPECIFICATIONS
poLy-v pULLEy rEmovAL
* 3mm Allen hex *Loctite 271 Tools Required:
SPECIFICATIONS
rIghT cLUTch/pULLEy rEpLAcEmEnT
Follow the steps in the “Left Clutch/Pulley Replacement” section for the right clutch/pulley #A1375.
Step 2:
Lift the left pedal to relieve the tension on
the return spring.
Spring tension
will be less
Lift left
pedal upward
Remove the console and lower/upper covers according to the “Lower/Upper Cover Removal” process.
Step 1:
Reattach the covers and console according to the “Lower/Upper Cover” replacement procedure on page 31.
