SPECIFICATIONS
MECHANICAL PARTS REMOVAL/REPLACEMENT
13
SCIFIT Scientic Solutions For Fitness SCIFIT Scientic Solutions For Fitness SCIFIT
Position the new angle indicator clamp as
shown in the drawing, so the “+30” is on
the right side.
Step 3:
Remove the clamp.
Step 1:
SPECIFICATIONS
LEFT AngLE InDIcATor cLAmp rEpLAcEmEnT
Tools Required: * Angle Clamp Separation Tool
SPECIFICATIONS
rIghT AngLE InDIcATor cLAmp rEmovAL
Follow the steps in the “Left Angle Indicator Clamp Removal” section to remove the right side angle
indicator clamp (#A5135).
