SPECIFICATIONS
rIghT oUTEr hAnDLE ASSEmBLy rEmovAL
Repeat the steps of the “Left Outer Handle Assembly Removal” section for the right outer handle
(#A5434).
SPECIFICATIONS
LEFT oUTEr hAnDLE ASSEmBLy rEpLAcEmEnT
Place a small amount of Loctite 271 onto
the threads of the screw, then loosely
attach the screw and at washer previously
removed.
271
Step 1:
Carefully place the new outer handle onto
the frame shaft.
Step 2:
Tools Required: * 7/ 32” Allen H ex * 1/ 4” Allen H ex * 5/ 8” S ocket * R atchet * L octite 271
* Torque wrench with range above 720 in/lbs *Small at head screwdriver
To Next Page
