SCIFIT STEP ONE - Left and Right Handlebars

SPECIFICATIONS
MECHANICAL REMOVAL/REPLACEMENT
5
SCIFIT Scientic Solutions For Fitness SCIFIT Scientic Solutions For Fitness SCIFIT
Tools Required:
Step 1: Place one hand on the seat cushion back support
and the ot her on t he f ront of t he s eat bot tom pad.
Step 2: Place your foot on, then push down and hold
the “ Foot Assist P edal” located in f ront of t he s eat.
Step 3: Slide the seat assembly backwards until
it i s completely off of t he m achine seat t rack.
TO REMOUNT: Put the seat assembly onto the track,
then press down on the “Foot Assist Pedal” to position
the seat assembly back onto the seat track.
REMOVE
PLACE
FOOT
HERE
* 3/16 T-Handle Allen Hex * Small Deadblow Hammer * Narrow Edge Plastic Punch
Use a 3/16 allen hex to remove the dog
point set screw (#25903)
Step 1:
SPECIFICATIONS
LEFT hAnDLEBAr rEmovAL
FIXED/SWIvEL
