SPECIFICATIONS
MECHANICAL PARTS REMOVAL/REPLACEMENT
50
SCIFIT Scientic Solutions For Fitness SCIFIT Scientic Solutions For Fitness SCIFIT
Place the outer bearing cover onto the shaft
to cover the end of the clutch/pulley.
Outer bearing
cover
Secure the cover and clutch/pulley with the
snap ring previously removed.
Step 2:
Step 3:
Lift the left pedal and center the belt
onto the clutch/pulley. Verify that the
groove side of the belt is meshing with
the grooves of the pulley, then release the
pedal.
Belt
Step 4:
To Next Page
