SPECIFICATIONS
MECHANICAL PARTS REMOVAL/REPLACEMENT
59
SCIFIT Scientic Solutions For Fitness SCIFIT Scientic Solutions For Fitness SCIFIT
Step 2:
Position the the brake, so the mounting
studs are approximately 1/4” from the end
of the brake’s slot opening (See drawing).
1/4”
from
the end
Step 3:
Loosely place the four 1/4”-20 nylock
nuts (#1137018) and four M6 at washers
(#1140355) onto the mounting studs.
Step 4:
Use a 7/16 socket to secure the four
1/4”-20 nylock nuts and four M6 at
washers to the brake.
7/16 Socket
To Next Page
