71
SCIFIT Scientic Solutions For Fitness SCIFIT Scientic Solutions For Fitness SCIFIT
Cut tyraps
Use wire cutters to cut the two tywraps
that secure the battery (#63127) to the
bracket, then remove the battery.
Step 5:
JP2
Disconnect the battery cable (#P1833)
from “JP2” on the lower controller board.
Step 4:
SPECIFICATIONS
ELECTRICAL PARTS REMOVAL/REPLACEMENT
Disconnect the battery cable from the
battery (#P1564).
Step 6:
To Next Page
