4.1 PHYSICAL DIMENSIONS
INCHES CM
A. Floor to punch ram 43-1/4 109.8
B. Floor to top of die holder 39-1/2 100.3
C. Floor to punch bolster 35 88.9
D. Floor to bottom rail 3 7.6
E. Floor to Bar Shear 27-1/2 69.8
F. Floor to tool table 41-1/2 105.4
G. Height 64-1/2 163.8
H. Length 60-3/4 154.3
I. Punch stroke 2 5
J. Width 30 76.2
K. Weight 2,750 LBS. 1,250 KG.
