9.0 6509 IRONWORKER PARTS LISTS
THE FOLLOWING SECTION CONTAINS THE IRONWORKER PARTS LISTS AND DRAWINGS.
FOR YOUR CONVENIENCE, ALWAYS GIVE YOUR COMPLETE SERIAL NUMBER WHEN ORDERING PARTS.
9.1 SHEAR ARM ASSEMBLY SERIAL #'S 7815 & UP)
FOR OLDER MODELS, REFER TO SECTION 10.0.
ITEM QTY PART # DESCRIPTION
A 2 030650 Rub Block - Frame
A1 6 212012 M-10 Lock Washer
A2 8 214012 M-10 Regular Washer
A3 4 243101 M-6 x 13.5 OAL Gold Zerk
B 1 006240 Shear Arm Ass’y - Metric
C 2 010176 Bushing - Connecting Link Pins
D 1 080031 24” Metric Bar Blade
E 4 210014 M-12 Jam Nut
F 1 080427 XL Shear Table Sales
G 1 007249 Shear Arm Bushing
H 1 006129 Shear Arm Pin - Metric
I 2 080174 Grease Bolt - Main Pin
J 1 010177 Pressure Plate
K 2 007273 Brass Wear Plate
L 6 214017 1” Bokers Hard Washer
M 6 214014 M-12 Regular Washer
N 6 212014 M-12 Lock Washer
O 22 218120 M-12 x 50MM Set Screw
P 6 205422 M-12 x 55 HHCS
Q 6 221426 M-16 x 65MM SHCS
R 1 080428 Slug Chute - Bar Shear
S 1 006227 Slug Ramp
T 6 201220 M-10 x 50MM HHCS
U 12 218112 M-12 x 35MM FP Set Screw
V 2 006015 Shear Arm Rub Block - Metric
W 4 205425 M-12 x 65MM HHCS
X 1 013289 Shear Door Ass’y
Y 3 224005 M-6 x 12MM WLCS
Z 1 033175 24” 3/4 Bar Blade
AA 4 230210 M-10 x 30 FSHCS
BB 2 026618 Tee Nut (M-10)
