Page 72
9.2 PUNCH ASSEMBLY (Serial #’s 7937FF & Up)
ITEM QTY PART # DESCRIPTION
A 1 006260 Punch Bolster - Metric
B 5 221420 M-16 x 50MM SHCS
C 2 113017 1-3/4 OD x 21/32 ID Reid Washer
D 2 201625 M-16 X 65MM HHCS
E 1 006013 Die Holder - Metric
(Includes F)
F 2 218058 M-10 x 45MM DP Set Screw
G 1 006202 #82 Metric Die Insert
(Inc. H, I & J)
H 1 204220 M-10 x 30 10.9 HHCS
I 1 077145 M-7.5 x 20 Pin
J 1 219060 M-10 x 50FP Set Screw
K 1 016095 #40 XL Punch Retaining Nut
L 4 221312 M-12 x 30MM SHCS
M & W 1 010225 3” Punch Ram & Bushing
N 1 007232 Lower Punch Pin S.C.
O 2 016063 1-1/2" OD Snap Ring
P 2 016620 2" Snap Ring
Q 1 006164 Upper Punch Pin
& Bushing - Metric
R 1 210014 M-12 Jam Nut
S 1 006116 Strap (See Item HH)
T 1 006116 Strap (See Item HH)
U 3 243101 M-6 x 13.5 OAL Gold Zerk
V 1 201440 M-12 x 100MM HHCS
X 1 007142 Punch Ram Cover
Y 2 141019 3/16 x 1/2 Roll Pin
Z 2 224205 M-10 x 16MM WLCS
AA 1 015033 Insert (See Item GG)
BB 1 004123 1/4” Key (All Key Punch)
CC 2 015131 2.003 Brass Washer
DD 2 006115 1.53 Brass Washer
EE 1 012077 3” Punch Holder
FF 8 221120 M-8 x 25 12.9 SHCS
GG 1 015033 Insert w/Key -
(Includes Y, AA & BB)
HH 1 006116 Punch Link Kit - 65 Ton
II 3 230207 M-10 x 20 FSHCS
