Scotchman 6509-24FF - Tooling Parts

2.0TOOLINGPARTS
2.16X6ANGLESHEAR(Usedonmachinesafter08/1995)
6509:Ser.#5298FF 9012:Ser.#20874 12012:Ser.#50843
ITEM COMMON DESCRIPTION
PART#'S
A 026728 Housing
B 026735 LowerBlades
C 026732 Base
D 221210 M-10x25 SHCS
E 026237 UpperBlade
F 213012 M-10LockWasher
G 201212 M-10x35 HHCS
H 026740 RearGuardAssembly(2Required)
I 201230 M-10x70 HHCS
J 026242 SightGlass
K 016118 Spring
L 026243 WearStrip
M 026746 Retainer
N 201110 M-6x12 HHCS
O 026744 SpringBlock
P 204225 M-10x60 HHCS
Q 220014 M-6x10 BHCS
R 016247 SliderBlockAssembly
S 217012 M-10HexNut
T 026209 PressureBlock
U 219040 M-10x10SetScrew
V 243101 GreaseNipple(Notpictured)
X 201210 M-10x20 HHCS
Y 026727 CompleteAngleShear
Z 016233 Shim
AA 016234 Shim
BB 026747 FrontGuardAssembly
CC 016232 Shim&Guide-(Left)
DD 016230 Shim&Guide-(Right)
026727 CompleteTool
OPTIONALTOPBLADES
016238 4x3-1/2,3-1/2x3&3x2-1/2
016239 4x3,2-1/2x2&2x1-1/2
016240 6x4,5x3-1/2&3x2
016241 6x3-1/2&5x3
026708 QuickChangeHardware
ForUnequalBlade
PAGE4
