Page 36
7.0 OPTIONAL TOOL OPERATION
⌦
CAUTION: MOVE ALL TOOLS OUT FROM UNDER THE UPPER ARM WHEN THEY ARE
NOT IN USE.
When using the tool station, crank the bar shear hold-down device completely down and remove the
punch and die.
As with all functions on this machine, SAFETY GLASSES ARE REQUIRED when using optional
tools of any type.
Each self contained tool has its own stroke and tonnage requirements. This section will cover the
operation and location of each tool.
At the beginning of the section, there is a graphical illustration of the available tonnage at locations
along the Upper Arm. SEE FIGURE 13 ON THE FOLLOWING PAGE.
This graph will be helpful in setting up various Scotchman or custom tooling.
