3.0PUNCHESANDDIES
AllScotchmanpunchesanddiesaredesignedandmanufacturedforScotchmanproducts.Allpunches
anddiesaremadefromhighqualitytoolsteel.Thefollowingchartsgivepunchanddiedimensionsfor
variousstylesandsizes.Theyalsoshowwhattoolingisrequiredtoholdthevarioussizes.Inadditionto
thepunchesanddiesshown,Scotchmanmanufacturespunchesanddiesforspecialapplications.Please
contactyourdealerorthefactoryifyouhavesuchanapplication.
#40ROUNDPUNCHES&#82DIES(USE#40PUNCHRETAINING
NUT&STANDARD2"DIEHOLDERORINSERT)
1/8,5/32,3/16,7/32,1/4,9/32,5/16,11/32,3/8,13/32,7/16,
15/32,1/2,17/32,9/16,19/32,5/8,21/32,11/16,23/32,3/4,
25/32,13/16,27/32,7/8,29/32,15/16,31/32,1,1-1/32,1-1/16,
1-3/32,1-1/8,1-5/32,1-3/16,1-7/32,1-1/4
#45ROUNDPUNCHES&#86DIES(USE#45PUNCHRETAINING
NUT&2-1/2"DIEHOLDERORINSERT)
1-9/32,1-5/16,1-11/32,1-3/8,1-13/32,1-7/16,1-15/32,
1-1/2,1-17/32,1-9/16
OVERSIZEDROUNDPUNCHES(USEHEAVYDUTY
SPLIT-RINGRETAININGNUT)
1-19/32"UPTO1-15/16"
OVERSIZEDROUNDDIES
(USEOVERSIZED3"DIEHOLDERORINSERT)
