Page 56
7.10 SQUARE TUBE SHEAR
SEE FIGURE 25 ON THE FOLLOWING PAGE.
The square tube shear is designed to shear square tubing from 1/4" to 2".
16 gauge is the maximum material thickness.
7.10A SQUARE TUBE SHEAR INSTALLATION
SEE FIGURE 25 ON THE FOLLOWING PAGE.
This tool mounts on the tool table. The machine must be in the SHEAR position to operate this tool.
1. Mount the tool over the slug release slot in the table and squarely under the upper arm.
2. Grease the pressure cap (A) before using and every two hours, thereafter.
3. Anchor the tool with the finger clamps (C) provided.
4. Set the upstroke of the machine so that the size of tube you want to shear will feed through the
tool. Make sure that the upstroke is set so that there is spring tension on the pressure block at all
times.
5. Set the down stroke so that the upper blade passes the lower blade by approximately 1/8".
7.10B SQUARE TUBE SHEAR OPERATION
1. The selector switch must be in the SHEAR position to operate this tool.
2. Set the down stroke of the machine so that the upper blade passes the lower blade by
approximately 1/8 of an inch.
3. Feed the tubing through the shear to the desired length and depress the foot pedal.
4. Lubricate the blades every ten to fifteen cuts.
⌦
CAUTION: ALWAYS REMOVE THIS TOOL WHEN IT IS NOT IN USE.
