Ice Machine Series Voltage/Hz/Phase Compressor Start Winding
Ohms
Run Winding
Ohms
C0322 or C0330-1 A B D 115/60/1 AKA9438ZXA 4.22 .59
C0330-6 A or B 230/50 AKA9438ZXC 7.11 2.69
C0330-32 A or B 208-230/60/1 AKA9468ZXD 10.43 1.77
C0522 or C0530-1 A or B 115/60/1 AKA9451ZXA 5.95 .69
C0530-6 A or B 230/50 AKA9451ZXC 7.11 2.69
C0530-32 A or B 208-230/60/1 AKA9451ZXD 10.43 1.77
C0530 -1 C or D 115/60/1 RST45C1E-CAA
C0530 - 6 C or D 230/50/1 RST45C1E-CAB
C0530 - 32 C or D 208-230/60/1 RST45C1E-CAV
C0722 or C0630-32 A B D 208-230/60/1 AJA7490ZXD 2.74 1.52
C0630-6 A B D 230/50 AJA7490ZXC 2.23 2.02
C0830-32 A B D 208-230/60/1 CS10K6EPFV 3.10 1.16
C0830-6 A B D 230/50 CS10K6EPFJ 3.79 1.39
C0830-3 A B D 208-230/60/3 CS10K6ETF5 - 1.77
C1030-32 A B D 208-230/60/1 CS12K6EPFV 3.10 1.16
C1030-6 A B D 230/50 CS12K6EPFJ 3.79 1.39
C1030-3 A B D 208-230/60/3 CS12K6ETF5 - 1.77
C1448-32 A B D 208-230/60/1 CS14K6EPFV 2.66 1.08
C1448-6 A B D 230/50 CS14KSEPFJ 2.64 1.4
C1448-3 A B D 208-230/60/3 CS14K6ETF5 - -
C1848-32 A B D 208-230/60/1 CS20K6EPFV 2.37 .65
C1848-6 A B D 230/50 CS20K6EPFZ
C1848-3 A B D 208-230/60/3 CS20K6ETF5 - -
C2148-32 A B D WC 208-230/60/1 CS24K6EPFV 2.35 .53
C2148-6 WC A B D 230/50 CS24K6EPFZ
C2148-3 WC A B D 208-230/60/3 CS24K6ETF5 - -
C2148-32 R A B D 208-230/60/1 CS27K6EPFV 2.35 .53
C2148-6 R A B D 230/50 CS27K6EPFZ
C2148-32 R A B D 208-230/60/3 CS27K6ETF5
Compressor Electrical Chart
Resistance reading tolerance is +- 10%
