January 2015 Page 97
Curtain
• Push and hold the Off button to shut the machine off.
• Remove front panel.
• Remove evaporator cover.
• Push inside tab in to release front curtain pin from holder.
• Pull curtain from machine.
• Reverse to reassemble.
Note: Two plate machines must place curtain on correct evaporator. Exception is the articulated
curtain, which has magnets on both ends.
• Push and release the ON button to restart the machine.
Curtain switch
1. Push and hold the Off button to shut the machine off.
2. Disconnect electrical power
3. Remove front panel.
4. Remove evaporator cover.
5. Remove sound shield (when used)
6. Open control box.
7. Locate curtain switch on evaporator mounting bracket. Pull switch from its snaps or remove 2 screws.
8. Dismount wires from sump cover and remove from J7 or J8 connector on control board.
9. Reverse to reassemble. Be sure wires are re-mounted to sump cover edge.
Repair Section
Electrical Shock Hazard
Disconnect electrical
power before beginning
