Repair Section
Inlet Water Solenoid Valve
1 Disconnect electrical power
2 Shut off the water supply.
3 Remove front and left side panels.
4 Unplug wire from coil.
5 Disconnect water supply tube from the
inlet of the valve.
6 Disconnect the water outlet tube.
7 Remove the two mounting screws holding the valve to the back panel.
8 Pull the valve forward and out of the machine.
Fan Blade or Motor
1 Push and release the Off button
2 Disconnect electrical power.
3 Remove front panel, sound shield and left side panel.
4 Unplug fan motor wire leads.
5 Remove fan motor mounting brackets from shroud. Note: Fastener size is 3/8” hex
6 Carefully remove fan motor and blade assembly from machine cabinet.
7 Loosen set screw, pull fan blade from motor shaft.
8 If the blade is the only part being changed, reverse to reassemble. Note: blade mounts
purge to end of motor shaft.
9 If the motor will be changed, remove mounting brackets from fan motor. Note: Fastener
size is ¼” hex.
10 Reverse to reassemble.
Electrical Shock Hazard
Disconnect electrical
power before beginning
