Stationary Air Compressor System Operating Instructions
7 - Index
A
ASME storage cylinders
charging 28
description 13
Auxiliary air outlets
optional high pressure outlet 34
optional low pressure outlet 35
standard outlets 33
B
Bulk storage
description 13
C
Cab air enclosure
removal 16
Carbon monoxide monitor
ow control 21
Cascade storage
description 13
operation, lling the air storage system 28
Charging station
description 14
Compressor
features 7
oil level 17
pressure relief valves 8
serial number location 7
Compressor system
coil fuse, location 8
condensate container
draining 28
location 8
drive belt
checking 29
location 8
electrical box, location 8
inlet lter
checking 29
location 8
model number 7
oil ll cap, location 8
operation
AUTO or MANUAL mode 20
pressure relief valves, location 8
principle of operation 10
purication system
checking 29
location 8
shutdown 27
stage gauge panel, location 8
system diagram 10
Condensate container
draining 28
location 8
Control panel
description 12
Controller, X4
location 18
maintenance interval, checking 25
INFO button 25
operation 18
system run time, checking 25
Customer Service
contact information 5
D
DOT storage cylinders
charging 28
description 13
Dual pressure regulator
description 14
G
Gauges
compressor stage gauges 24
L
Lubrication
checking 17
M
Maintenance
condensate container 30
drive belt 30, 31
inlet lter 31
purication system 31
routine, general 7
Maintenance record 43
Model
unit number location 7
