4 Panel
4.1Product mix
Name and function description
Name
Description
①
Power interface
3Pin push in terminal
②
Bus interface
2×RJ45
③
Network port indicator
Link and data transmission status
④
System indicator
Indicates the module status
⑤
Module identification
Mark the module model, bus type, etc
⑥
Channel interface
The 2×20Pin push in terminal
⑦
Channel ID
Corresponding channel position identification
⑧
Channel indicator
Indicates the corresponding channel signal status
