3 Product Parameters
3.1General parameters
Interface parameters
Bus protocol
EtherCAT
Number of I/O stations
Depending on master station configuration
Data transmission medium
Ethernet/EtherCAT CAT5 cable
Transmission distance
≤100 m (distance between stations)
Transmission speed
100 Mbps
Bus interface
2×RJ45
Technical parameters
Configuration method
Through the main station
Power supply rating (range)
24 VDC （18V~36V ）
Electrical isolation
500 VAC
Weight
About 140g
Dimensions
102mm×72mm×25 mm
Working temperature
-10℃~+60℃
Storage temperature
-20℃~+75℃
Relative humidity
95%, with no condensation
Protection degree
IP20
