EC4 series integrated I/O user manual Use
Copyright © Nanjing Solidot Electronic Technology Co., LTD. 2023
Deplication length requirements
The recommended stripping length is 10 mm.
Single strand hard wire, after stripping the corresponding length
of the wire, the down button will insert the single strand at the
same time.
Multiple flexible wire, after stripping the corresponding length, use
the corresponding standard cold pressure terminal (pipe insulation
terminal, reference specification is shown in the following table), and lower the pressure button to insert
the wire at the same time.
Specification table of pipe-type insulated end head
Length of the tube-type insulated terminal L is 10 mm
To Next Page
