21
1. Safety Lanyard
(engine cut-out switch)
2. Steering Wheel
3. Throttle/Shift Lever
4. Ignition Switch
5. 12-Volts Accessory Jack
6. Navigation Light Switch
7. Bilge Pump Switch
8. Bilge Air Blower Switch
9. Horn Switch
10. Deck Light Switch
11. Fuel Gauge/Low Oil Level Pilot
Lamp and Beeper
12. Tachometer
13. Speedometer
14. Windshield
15. Bilge Drain Plugs
16. Grab Handles
17. Rear Grab Handles
18. Swim Platform
19. Sun Deck
20. Seats
21. Bow Seats
22. Cup Holders
23. Rear Seat Storage Compartment
24. Rear Storage Compartment
25. Jet Pump Water Intake
26. Bow and Stern Eyelets
27. Bow Light
28. Removable Stern Light
29. Mooring Cleats
30. Deck
31. Fuel Tank Cap
32. Deck Drain(s)
33. Main Oil Reservoir Cap
34. Flushing Connector
35. Ventilation Ducts
36. Jet Pump Nozzle
37. Reverse Gate
38. Retractable Ladder
39. Hydro-Surge Grate System
40. Fuel Tank Vent
41. Fuses
42. Radio (if so equipped)
43. Glove Box (if so equipped)
44. Water Bypass System
45. Main Battery Cut-Off Switch
F10L2NL
35
15
35
44
18
26
17
40
26
38
25-39
36 37 15
45
lmo2001-004a.book Page 21 Friday, November 3, 2000 3:27 PM
