Sea-doo Utopia Operator's Manual

53
Navigation Light Bulb
Replacement
Bow Light
TYPICAL
1. Gently pry here with a screwdriver
TYPICAL
1. Remove this screw
TYPICAL
1. Pull lens out
TYPICAL
1. Lift and remove bulb
The assembly is essentially the re-
verse of removal procedures. Howev-
er, pay particular attention to the fol-
lowing:
Apply dielectric grease on bulb contact
surface.
When installing the bulb under the up-
per terminal plate, it is possible that
the bulb remains loose. The cover will
compress the terminal plate against
the bulb at reinstallation.
Stern Light
Unscrew lens counterclockwise and
pull it out.
1. Unscrew then pull
F04H2QY
1
F04H2RY
1
F04H2SY
1
F04H2TY
1
F04H2UY
1
lmo2001-004b.fm Page 53 Thursday, November 16, 2000 4:05 PM
