25
Press and hold the switch to activate
horn.
Release the switch to stop horn.
10) Deck Light Switch
A 2-position push type switch.
CAUTION: Using the deck lights for
a prolonged time when the engine is
not running will discharge the bat-
tery.
11) Fuel Gauge/Low Oil
Level Pilot Lamp and
Beeper
TYPICAL
1. Low injection oil level pilot lamp
2. Fuel level
Fuel Gauge
Located in dashboard, the analog gauge
continuously indicates the amount of
fuel in fuel tank when engine is running.
The gauge is illuminated whenever the
navigation lights are used.
NOTE: The fuel level can also be veri-
fied without having engine running.
With the safety lanyard removed from
its switch, turn ignition switch to ON
position; the gauge will be activated.
CAUTION: Always turn ignition switch
to OFF position once fuel level has
been checked.
Low Oil Level Pilot Lamp and
Beeper
The pilot lamp and the beeper turn on
when the oil level is low in engine mount-
ed oil reservoir or if a wire/connector of
this electrical circuit is not properly con-
nected. Fill reservoirs as soon as possi-
ble or contact an authorized SEA-DOO
Sport Boat dealer if light or beeper re-
main on.
CAUTION: Never run engine out of
oil. Serious engine damage will occur.
12) Tachometer
Analog tachometer indicates the revo-
lutions per minute (RPM) of the en-
gine. Multiply reading by 100 to obtain
actual RPM.
F00H1KY
F10H0GY
12
F10H0HY
lmo2001-004a.book Page 25 Friday, November 3, 2000 3:27 PM
