Sea Tel ST144-21 - Close the 168 Radome Assembly

Installation ST144-21 C/Ku-Band TVRO
3-18
3.4.5.
Refer to the Radome Assembly drawing for your system and the procedure below.
Close the 168” Radome Assembly
1. Lift Upper section up over the dish &
feed assembly and set it down onto
the lower section.
2. Set the upper section onto the top of
the lower panels.
3. Loosely attach the upper panels to the
lower panels using the hardware
provided. Do NOT tighten the bolts at
this time.
