Sea Tel ST144-21 - ACU Factory Default Parameters

Basic Setup of the ACU ST144-21 C/Ku-Band TVRO
4-2
4.4. ACU Factory Default Parameter Settings – STxxx-21 Series Antennas
The following table shows the factory default parameters for the ACU interfaced to a ST-21 Series Antenna. You may
need to optimize some of these parameters. Refer to the individual parameter setting information in the Setup section
of your ACU manual.
PARAMETER C-Band
DishScan®
Ku-Band
DishScan®
My Parameters
EL TRIM 0
AZ TRIM 0
AUTO THRES 100
EL STEP SIZE 0
AZ STEP SIZE 0
STEP INTEGRAL 0
SEARCH INC 30 15
SEARCH LIMIT 200 100
SEARCH DELAY 30
SWEEP INC 0040
SYSTEM TYPE 0005
GYRO TYPE 2
POL TYPE 72
POL OFFSET 30
POL SCALE 90
AZ LIMIT 1 0
AZ LIMIT 2 0
EL LIMIT 12 0
AZ LIMIT 3 0
AZ LIMIT 4 0
EL LIMIT 34 0
AZ LIMIT 5 0
AZ LIMIT 6 0
EL LIMIT 56 0
5V OFFSET 0
5V SCALE 0
TRACK DISP Refer to TRACK DISP parameter
TX POLARITY 2
REMOTE PARAMETER ST88-21 ST94-21 ST144-21
PCU Configuration Number N0xxx 212 213 208
DishScan Phase/Gain N7xxx 149 149 192
Home Flag Offset N6xxx 000 000 000
