SEA USER 1 - General and Technical Information; Technical Specifications

GENERAL INFORMATION
TECHNICAL SPECIFICATIONS
Control unit power supply
Absorption in stand by
Max. motor charge
Max. accessories charge 24V
Max. Flash light charge
Environment temperature
Protection 24V~
Function logic
Opening/closing time
Time of pause
Thrust
Slow down
Input on connecting terminal
Output on connecting terminal
Board dimensions
Specifications of optional batteries
Specifications of external enclosure
Special accessories
The information in this section of the manual are only for technicians or for qualified or authorized
installers.
GENERAL CHARACTERISTICS
The USER 1 24V DG control unit has been designed to manage one low voltage motor with or without electronic limit
switches.
It is of very small size and the big news is the LCD display on board that let you view and set in a simple and complete
way all functions of the control unit.
USER 1 - 24V DG
24 V~
30 mA
200W
24V 250mA
24V (FL) 15W max.
-20°C +50°C
F1 (6.3 AT)
Automatic/S.by Step1/S.By Step2/Sec./Dead man/2Butt.
In selflearning in programming phase
Adjustable (from to 4 min)
Adjustable Opening and Closing
Adjustable Opening and Closing
Battery power supply / Total opening / Pedestrian
opening adjustable / Balanceable edge /
Stop / Limit switch opening and closing / Photocell 1
and Photocell 2
24V(FL) / Light (Max 100 mA) /
Motor 24V / 24Vaux
156 x 100 mm
24V Pb 1.2Ah min.
305 x 225 x 125 mm - Ip55
Battery charger card (cod.23101105),
Programmer JOLLY (cod.23105276),
Programmer OPEN (cod.23105290)
D sb
The herein reported functions are available starting from revision 24.
International registered trademark n. 2.777.971
7
67411535 REV 03 - 05/2013
