SET-UP
F02L3W6
Peel off p ro
tective film from g asket (included in
predelivery kit ) and position on fiberglass surface.
NOTE: Before installing gasket, make sure
body surface is dry and clean. Use appropriate
body and hu
ll cleaner.
Open front storage cover and remove
storage tray (if so equipped).
Model(s): RXT and GTX International
Model(s)
: International
F02K0M6
Insert throttle cable and s teering harness through
conso
le hole and position steering assembly.
2
1
F02K0N6
Attach stee
ring cable end [2] to steering
stem arm [1] and secure with the M6 x 30
hexagonal bolt from predelivery kit .
Apply Loctite 243 (blue – threadlocker)
on bolt thr
eads.
Torqueto5N•m(44lbf•in).
NOTE: Ensu
re threads protrude through
elastic nuts
2 12
F18K066
Secure steering assembly [1] with4M8
flat washers [2] and4M8elasticnuts
from predelivery kit .
Apply
Loctite 243 (blue – threadlocker)
on bolt threads.
Torque to 12 N•m (9 lbf•ft).
10 / 22 2007-2 Predelivery
