Seaga JDL-2 COMBO - Page 16

16JDL V1.0 8 2022
Figure 15 – Loaded Product with Retainers Secured
Retainer
Adjusted within ½”
of product
Locking Arm Secured
Refer to Figure 16 below for alternate product requirements and the accessories needed to properly vend
these items.
Size Descripon Product Setup/Accessory Load Capacity Group
20 oz
519 ml
Bole
Aquana Water,
Country Time
Lemonade, Lip-
ton Iced or Green
Tea, Coke, Pep-
si, and Various
Brands
Side Spacer, Small, LH Tops to Back 10 1
14 oz
414 ml
Bole Nesquik Side Spacer, Small, LH Tops to Back 10 1
18.5 oz
547 ml
Bole Pure Leaf Tea Side Spacer, Small, LH
Alternate top and
boom
10 2
20 oz
519 ml
Bole
Gatorade, Sobe,
Vitamin Water
Not Required Tops to Back 10 3
16 oz
473 ml
Can
Monster, Rock
Star
Side Spacer, Small, LH,
Back Spacer
Alternate top and
boom
10 4
15 oz
443 ml
Can
Starbucks Dou-
bleshot Coee
Side Spacer, Small, LH,
Back Spacer
Alternate top and
boom
10 4
