Card Reader 1 and 2 Errors
Error Message Descripon Possible Soluons
Card RDR1 or 2 Comm VMC does not have communica-
on with the card reader.
Check MDB Harness to card reader.
Check for power on card reader.
Card RDR1 or 2 Err The card reader reports an error See card reader service manual.
NOTE: Errors are cleared aer the problem detected has been resolved.
VEND MOTORS
CAUTION: Vend motors from the snack poron are NEVER to be used in the Beverage poron. Failure to follow
this cauon could result in re or explosion.
Each Selecon is vended by the acon of the Vend Motor. The Vend Motors are screwed onto the rear of each
snack selecon and the front of the beverage selecons. In the rare event of a jam, a Vend Motor may need to
be returned to its home posion.
Figure 22 – Motors for Snack Tray and Beverage Unit
Unplug motor
harness
Snack Motor Beverage Motor
Unscrew two
screws
Pinch to remoe
coil driver
ELC920
Unplug motor
harness
Unscrew
two blue
thumbscrews
ELC930
