INSTALLATION
MANUAL
Product:
Document #:
Rev:
Page:
SEAKEEPER 3 90378 4 2 of 12
Section 2: ELECTRICAL INSTALLATION
2.1 Electrical Equipment Mounting
Precautions
Each item of electrical equipment has specific mounting instructions. These instructions
should be followed to insure proper function of the Seakeeper.
1. TOUCH DISPLAY MOUNTING INSTRUCTIONS, SURFACE MOUNT
a. Console space required: Approx. 5.24 W x 3.70 H inches (133 x 94 mm)
b. Mounting Instructions, Surface Mount: See drawing 90438 for details
2. CAN COMMUNICATIONS TEE ADAPTER AND TERMINATOR MOUNTING
INSTRUCTIONS
a. Console space required, Rear: Approx. 4 W x 3 H inches (102 x 76 mm), rear
b. Mounting Instructions: Rear mount on vessel console panel, within 2 ft (0.6m) of
Display.
c. Hardware required: One mounting screw for .197” (5 mm) diameter mounting
hole on Tee Adapter.
Do NOT move Seakeeper mounted components from their
locations or incorrect Seakeeper operation will result.
