Section 5: INSTALLATION CHECKLIST AND SUPPLIES
5.1 Required Supplies needed for Seakeeper Installation
(not supplied with the Seakeeper)
Item Description Qty
Installation
Manual
Reference
Section
Other
Reference
System
1
Soundproofing Considerations
1
Mechanical
2
Spreader bar for lifting the Seakeeper
1
Mechanical
3
Hose clamps for seawater plumbing to 3/4" (19 mm)
hose barb (2 per hose barb)
4 3 Cooling
4
M6 terminal lug for grounding Seakeeper at rear brace
1
2.3.1
Electrical
5
Cable, 4 AWG, for grounding Seakeeper at rear brace
to vessel ground (used with item 4)
AR 2.3.1 Dwg 90377 Electrical
6
Seawater pump, 12 VDC 3A (Fuse protection included
in Seakeeper wiring harness)
1 2.2.3 Electrical
7
Relay for seawater pump control
(Not required if using 12 VDC 3A pump)
1 2.2.3 Electrical
8
100A Circuit breaker for Conductor 1
1
Electrical
9
15A Circuit breaker for Cable 7
1
Electrical
AR = As Required
Dwg = Drawing
List of common tools that may be required for installation
Item
Description
Use
1
Wire cutter
DC Power cables
2
Wire stripper
DC Power cables
3
3 mm hex key
Gimbal sensor mount plate
4
2.5 mm hex key
Gimbal angle sensor
5
1/4 inch nutdriver
Hose clamps
6
Quick Cable 4245 Crimp Tool, Molex
19284-0034 Crimp Tool, or equivalent
Power cables
7
Utility knife
Scoring cable jackets
